E-ONE parts
E-ONE part search
Search by part number, OEM number, or vehicle. The part page shows whether it is active or a reference listing.
- 01 / Search
- Start with the part number, OEM reference, or application text you already have.
- 02 / Narrow
- Use the filters to keep the closest matches in front of you.
- 03 / Check
- Open the part page for measurements, references, and the right way to contact APM USA.
Matching parts
E-ONE part pages in catalog
Split into 1 browse section. Open the part page when the fit looks close.
20 shown part numbers are reference listings, not current catalog parts.
Browse section
Multi-leaf
Use the part pages below. There is no separate family page for this group.
41-200
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 8 leaves
- A-side length (La)
- 28-11/16"
- B-side length (Lb)
- 28-11/16"
- Camber / free arch (C)
- 5-1/8"
- Width / thickness (W)
- 4 width
41-202
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 10 leaves
- A-side length (La)
- 28-11/16"
- B-side length (Lb)
- 28-11/16"
- Camber / free arch (C)
- 5-3/4"
- Width / thickness (W)
- 4 width
41-204
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 11 leaves
- A-side length (La)
- 28-11/16"
- B-side length (Lb)
- 28-11/16"
- Camber / free arch (C)
- 5-13/16"
- Width / thickness (W)
- 4 width
41-206
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 8 leaves
- A-side length (La)
- 28-11/16"
- B-side length (Lb)
- 28-11/16"
- Camber / free arch (C)
- 4-3/4"
- Width / thickness (W)
- 4 width
41-208
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 9 leaves
- A-side length (La)
- 28-11/16"
- B-side length (Lb)
- 28-11/16"
- Camber / free arch (C)
- 4-13/16"
- Width / thickness (W)
- 4 width
41-210
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 7 leaves
- A-side length (La)
- 28-11/16"
- B-side length (Lb)
- 28-11/16"
- Camber / free arch (C)
- 5-7/16"
- Width / thickness (W)
- 4 width
41-212
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Single stage
- Leaf count
- 12 leaves
- A-side length (La)
- 25"
- B-side length (Lb)
- 29"
- Camber / free arch (C)
- 3-1/2"
- Width / thickness (W)
- 4 width
41-214
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 3 leaves
- A-side length (La)
- 25"
- B-side length (Lb)
- 29"
- Camber / free arch (C)
- 3-9/16"
- Width / thickness (W)
- 4 width
41-244
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 3 leaves
- A-side length (La)
- 25"
- B-side length (Lb)
- 29"
- Camber / free arch (C)
- 3-3/4"
- Width / thickness (W)
- 4 width
41-250
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 3 leaves
- A-side length (La)
- 25"
- B-side length (Lb)
- 29"
- Camber / free arch (C)
- 3-3/4"
- Width / thickness (W)
- 4 width
41-252
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 3 leaves
- A-side length (La)
- 25"
- B-side length (Lb)
- 29"
- Camber / free arch (C)
- 3-3/4"
- Width / thickness (W)
- 4 width
41-254
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 3 leaves
- A-side length (La)
- 25"
- B-side length (Lb)
- 29"
- Camber / free arch (C)
- 4-7/16"
- Width / thickness (W)
- 4 width
41-256
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 3 leaves
- A-side length (La)
- 25"
- B-side length (Lb)
- 29"
- Camber / free arch (C)
- 3-3/4"
- Width / thickness (W)
- 4 width
41-258
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 3 leaves
- A-side length (La)
- 25-1/8"
- B-side length (Lb)
- 29"
- Camber / free arch (C)
- 3-3/4"
- Width / thickness (W)
- 4 width
41-260
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 3 leaves
- A-side length (La)
- 25"
- B-side length (Lb)
- 29"
- Camber / free arch (C)
- 3-9/16"
- Width / thickness (W)
- 4 width
41-262
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 3 leaves
- A-side length (La)
- 25"
- B-side length (Lb)
- 29"
- Camber / free arch (C)
- 3-3/4"
- Width / thickness (W)
- 4 width
41-264
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 3 leaves
- A-side length (La)
- 25"
- B-side length (Lb)
- 29"
- Camber / free arch (C)
- 3-3/4"
- Width / thickness (W)
- 4 width
41-266
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 3 leaves
- A-side length (La)
- 25"
- B-side length (Lb)
- 29"
- Camber / free arch (C)
- 3-7/8"
- Width / thickness (W)
- 4 width
41-902
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 3 leaves
- A-side length (La)
- 25"
- B-side length (Lb)
- 29"
- Camber / free arch (C)
- 3-3/4"
- Width / thickness (W)
- 4 width
41-904
Under developmentE-ONE
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 3 leaves
- A-side length (La)
- 25"
- B-side length (Lb)
- 29"
- Camber / free arch (C)
- 4-1/4"
- Width / thickness (W)
- 4 width
