Matching parts
GMC part pages in catalog
Split into 2 browse sections. Open the part page when the fit looks close.
21 shown part numbers are reference listings, not current catalog parts.
Browse section
Front · Multi-leaf
Use the part pages below. There is no separate family page for this group.
96-154
Active catalogGMC TRUCK
1 OEM reference
- Position
- Front
- Spring group
- Multi-leaf
- Spring stage
- Single stage
- Leaf count
- 11 leaves
- A-side length (La)
- 26-1/4"
- B-side length (Lb)
- 26-1/4"
- Camber / free arch (C)
- 3"
- Eye Diameter (Ø Eye)
- 1-3/8"
- Load capacity
- 9500 pounds
Browse section
Multi-leaf
Use the part pages below. There is no separate family page for this group.
48-546
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 3 OEM references
- Spring group
- Multi-leaf
- Spring stage
- Single stage
- Leaf count
- 8 leaves
- A-side length (La)
- 23-3/4"
- B-side length (Lb)
- 32-1/4"
- Camber / free arch (C)
- 5-7/8"
- Width / thickness (W)
- 4 width
48-558
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Single stage
- Leaf count
- 3 leaves
- A-side length (La)
- 23-3/4"
- B-side length (Lb)
- 32-1/4"
- Camber / free arch (C)
- 6-3/4"
- Width / thickness (W)
- 4 width
48-606
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references
- Spring group
- Multi-leaf
- Spring stage
- Single stage
- Leaf count
- 8 leaves
- A-side length (La)
- 23-3/4"
- B-side length (Lb)
- 32-1/4"
- Camber / free arch (C)
- 5-1/4"
- Width / thickness (W)
- 4 width
48-608
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 8 leaves
- A-side length (La)
- 23-3/4"
- B-side length (Lb)
- 32-1/4"
- Camber / free arch (C)
- 5-1/4"
- Width / thickness (W)
- 4 width
48-610
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 8 leaves
- A-side length (La)
- 23-3/4"
- B-side length (Lb)
- 32-1/4"
- Camber / free arch (C)
- 5-5/8"
- Width / thickness (W)
- 4 width
48-612
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 8 leaves
- A-side length (La)
- 23-3/4"
- B-side length (Lb)
- 32-1/4"
- Camber / free arch (C)
- 5-5/8"
- Width / thickness (W)
- 4 width
48-614
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Single stage
- Leaf count
- 9 leaves
- A-side length (La)
- 23-3/4"
- B-side length (Lb)
- 32-1/4"
- Camber / free arch (C)
- 5-1/2"
- Width / thickness (W)
- 4 width
48-616
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Single stage
- Leaf count
- 7 leaves
- A-side length (La)
- 25"
- B-side length (Lb)
- 35"
- Camber / free arch (C)
- 4-7/8"
- Width / thickness (W)
- 4 width
48-618
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Single stage
- Leaf count
- 3 leaves
- A-side length (La)
- 25"
- B-side length (Lb)
- 35"
- Camber / free arch (C)
- 5-1/4"
- Width / thickness (W)
- 4 width
48-620
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Single stage
- Leaf count
- 8 leaves
- A-side length (La)
- 23-3/4"
- B-side length (Lb)
- 32-1/4"
- Camber / free arch (C)
- 5-1/4"
- Width / thickness (W)
- 4 width
48-622
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Single stage
- Leaf count
- 9 leaves
- A-side length (La)
- 23-3/4"
- B-side length (Lb)
- 32-1/4"
- Camber / free arch (C)
- 5"
- Width / thickness (W)
- 4 width
48-624
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 8 leaves
- A-side length (La)
- 23-3/4"
- B-side length (Lb)
- 32-1/4"
- Camber / free arch (C)
- 4-5/8"
- Width / thickness (W)
- 4 width
48-935
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 14 leaves
- A-side length (La)
- 29-1/2"
- B-side length (Lb)
- 29-1/2"
- Camber / free arch (C)
- 5-5/8"
- Width / thickness (W)
- 3 width
48-937
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 13 leaves
- A-side length (La)
- 29-1/2"
- B-side length (Lb)
- 29-1/2"
- Camber / free arch (C)
- 5-5/8"
- Width / thickness (W)
- 3 width
48-939
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Single stage
- Leaf count
- 13 leaves
- A-side length (La)
- 28"
- B-side length (Lb)
- 28"
- Camber / free arch (C)
- 4-7/8"
- Width / thickness (W)
- 3 width
48-941
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 3 leaves
- A-side length (La)
- 22-1/2"
- B-side length (Lb)
- 22-1/2"
- Camber / free arch (C)
- 2-1/8"
- Width / thickness (W)
- 3 width
48-943
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 3 leaves
- A-side length (La)
- 22-5/16"
- B-side length (Lb)
- 24-5/8"
- Camber / free arch (C)
- 12-1/8"
- Width / thickness (W)
- 3 width
48-945
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references
- Spring group
- Multi-leaf
- Spring stage
- Single stage
- Leaf count
- 12 leaves
- A-side length (La)
- 17"
- B-side length (Lb)
- 28-1/2"
- Camber / free arch (C)
- 2-1/8"
- Width / thickness (W)
- 4 width
48-947
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 17 leaves
- A-side length (La)
- 29-5/8"
- B-side length (Lb)
- 29-5/8"
- Camber / free arch (C)
- 7-3/4"
- Width / thickness (W)
- 3 width
48-949
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 8 leaves
- A-side length (La)
- 22-1/2"
- B-side length (Lb)
- 22-1/2"
- Camber / free arch (C)
- 3"
- Width / thickness (W)
- 3 width
48-951
Under developmentGMC
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Single stage
- Leaf count
- 1 leaves
- A-side length (La)
- 15-1/2"
- B-side length (Lb)
- 24-1/4"
- Camber / free arch (C)
- '--"
- Width / thickness (W)
- 5 width
