Matching parts
KME part pages in catalog
Split into 1 browse section. Open the part page when the fit looks close.
13 shown part numbers are reference listings, not current catalog parts.
Browse section
Multi-leaf
Use the part pages below. There is no separate family page for this group.
41-600
Under developmentKME
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 9 leaves
- A-side length (La)
- 26-1/4"
- B-side length (Lb)
- 26-1/4"
- Camber / free arch (C)
- 4-5/16"
- Width / thickness (W)
- 3-1/2 width
41-601
Under developmentKME
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 16 leaves
- A-side length (La)
- 29-5/8"
- B-side length (Lb)
- 29-5/8"
- Camber / free arch (C)
- 7"
- Width / thickness (W)
- 3 width
41-602
Under developmentKME
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 8 leaves
- A-side length (La)
- 26-1/4"
- B-side length (Lb)
- 26-1/4"
- Camber / free arch (C)
- 3-7/8"
- Width / thickness (W)
- 3-1/2 width
41-603
Under developmentKME
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 14 leaves
- A-side length (La)
- 30-1/4"
- B-side length (Lb)
- 30-1/4"
- Camber / free arch (C)
- 6-3/8"
- Width / thickness (W)
- 3 width
41-604
Under developmentKME
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 9 leaves
- A-side length (La)
- 26-1/4"
- B-side length (Lb)
- 26-1/4"
- Camber / free arch (C)
- 3-7/8"
- Width / thickness (W)
- 3-1/2 width
41-605
Under developmentKME
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 16 leaves
- A-side length (La)
- 30-1/4"
- B-side length (Lb)
- 30-1/4"
- Camber / free arch (C)
- 6-3/8"
- Width / thickness (W)
- 3 width
41-607
Under developmentKME
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Single stage
- Leaf count
- 4 leaves
- A-side length (La)
- 19"
- B-side length (Lb)
- 19"
- Camber / free arch (C)
- 2-3/8"
- Width / thickness (W)
- 3 width
41-608
Under developmentKME
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Single stage
- Leaf count
- 11 leaves
- A-side length (La)
- 26-1/4"
- B-side length (Lb)
- 26-1/4"
- Camber / free arch (C)
- 4-3/16"
- Width / thickness (W)
- 3-1/2 width
41-609
Under developmentKME
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Single stage
- Leaf count
- 4 leaves
- A-side length (La)
- 19-3/4"
- B-side length (Lb)
- 19-3/4"
- Camber / free arch (C)
- 2-15/16"
- Width / thickness (W)
- 3 width
41-610
Under developmentKME
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 10 leaves
- A-side length (La)
- 26-1/4"
- B-side length (Lb)
- 26-1/4"
- Camber / free arch (C)
- 3-5/8"
- Width / thickness (W)
- 3-1/2 width
41-612
Under developmentKME
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 4 leaves
- A-side length (La)
- 26-5/16"
- B-side length (Lb)
- 30-1/8"
- Camber / free arch (C)
- 5-5/8"
- Width / thickness (W)
- 4 width
41-614
Under developmentKME
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 4 leaves
- A-side length (La)
- 26-5/16"
- B-side length (Lb)
- 30-1/8"
- Camber / free arch (C)
- 5-11/16"
- Width / thickness (W)
- 4 width
41-616
Under developmentKME
APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference
- Spring group
- Multi-leaf
- Spring stage
- Progressive
- Leaf count
- 4 leaves
- A-side length (La)
- 26-5/16"
- B-side length (Lb)
- 30-1/8"
- Camber / free arch (C)
- 5-11/16"
- Width / thickness (W)
- 4 width
