Pierce parts

01 / Search
Start with the part number, OEM reference, or application text you already have.
02 / Narrow
Use the filters to keep the closest matches in front of you.
03 / Check
Open the part page for measurements, references, and the right way to contact APM USA.

Matching parts

Pierce part pages in catalog

Split into 2 browse sections. Open the part page when the fit looks close.

77 shown part numbers are reference listings, not current catalog parts.

Part groups2
Part pages78
Reference77

Browse section

Rear · Multi-leaf

Use the part pages below. There is no separate family page for this group.

1 part page

This section only

  1. 41-019

    Active catalog

    PIERCE 403773,41019ME

    1 OEM reference

    Position
    Rear
    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    12 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    4-15/16"
    Eye Diameter (Ø Eye)
    1-3/8" both eyes
    Load capacity
    12500 lb
    Part detailsOpen part page

Browse section

Multi-leaf

Use the part pages below. There is no separate family page for this group.

77 part pages

This section only

  1. 41-001

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    A-side length (La)
    25-1/2"
    B-side length (Lb)
    25-1/2"
    Camber / free arch (C)
    3-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  2. 41-002

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    26-1/4"
    B-side length (Lb)
    26-1/4"
    Camber / free arch (C)
    4-1/4"
    Width / thickness (W)
    3-1/2 width
    Part detailsOpen part page

  3. 41-003

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    15 leaves
    A-side length (La)
    25-1/2"
    B-side length (Lb)
    25-1/2"
    Camber / free arch (C)
    3-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  4. 41-004

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    26-1/4"
    B-side length (Lb)
    26-1/4"
    Camber / free arch (C)
    4-5/16"
    Width / thickness (W)
    3-1/2 width
    Part detailsOpen part page

  5. 41-005

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    6 leaves
    A-side length (La)
    17-3/8"
    B-side length (Lb)
    17-3/8"
    Camber / free arch (C)
    3"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  6. 41-006

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    13 leaves
    A-side length (La)
    26-1/4"
    B-side length (Lb)
    26-1/4"
    Camber / free arch (C)
    4-1/4"
    Width / thickness (W)
    3-1/2 width
    Part detailsOpen part page

  7. 41-007

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    A-side length (La)
    25-1/2"
    B-side length (Lb)
    25-1/2"
    Camber / free arch (C)
    3-3/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  8. 41-008

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    15 leaves
    A-side length (La)
    26-1/4"
    B-side length (Lb)
    26-1/4"
    Camber / free arch (C)
    3-15/16"
    Width / thickness (W)
    3-1/2 width
    Part detailsOpen part page

  9. 41-009

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    15 leaves
    A-side length (La)
    25-5/16"
    B-side length (Lb)
    25-5/16"
    Camber / free arch (C)
    3-3/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  10. 41-010

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    6-3/16"
    Width / thickness (W)
    3-1/2 width
    Part detailsOpen part page

  11. 41-011

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    6 leaves
    A-side length (La)
    17-3/8"
    B-side length (Lb)
    17-3/8"
    Camber / free arch (C)
    2-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  12. 41-012

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3-1/2 width
    Part detailsOpen part page

  13. 41-013

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    16 leaves
    A-side length (La)
    25-13/16"
    B-side length (Lb)
    25-13/16"
    Camber / free arch (C)
    4-9/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  14. 41-014

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    9 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    5-3/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  15. 41-015

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    10 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    4-15/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  16. 41-016

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    11 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    4-7/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  17. 41-017

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    6-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  18. 41-018

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    9 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    5"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  19. 41-020

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    9 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    6-5/8"
    Width / thickness (W)
    3-1/2 width
    Part detailsOpen part page

  20. 41-021

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    11 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  21. 41-022

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    9 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    6"
    Width / thickness (W)
    3-1/2 width
    Part detailsOpen part page

  22. 41-023

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    10 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    3-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  23. 41-024

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    5-3/16"
    Width / thickness (W)
    3-1/2 width
    Part detailsOpen part page

  24. 41-025

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    9 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    5-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  25. 41-026

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    9 leaves
    A-side length (La)
    25-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    4-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  26. 41-027

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    5-5/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  27. 41-028

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    9 leaves
    A-side length (La)
    25-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  28. 41-029

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    3 leaves
    A-side length (La)
    18-13/16"
    B-side length (Lb)
    21-5/16"
    Camber / free arch (C)
    2-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  29. 41-030

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    4-5/8"
    Width / thickness (W)
    3-1/2 width
    Part detailsOpen part page

  30. 41-031

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    26"
    B-side length (Lb)
    26"
    Camber / free arch (C)
    4-5/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  31. 41-032

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    25-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    5-5/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  32. 41-033

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    26"
    B-side length (Lb)
    26"
    Camber / free arch (C)
    5-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  33. 41-034

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3-1/2 width
    Part detailsOpen part page

  34. 41-035

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    12 leaves
    A-side length (La)
    26"
    B-side length (Lb)
    26"
    Camber / free arch (C)
    4-13/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  35. 41-036

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    11 leaves
    A-side length (La)
    26-1/4"
    B-side length (Lb)
    26-1/4"
    Camber / free arch (C)
    5"
    Width / thickness (W)
    3-1/2 width
    Part detailsOpen part page

  36. 41-037

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    11 leaves
    A-side length (La)
    26"
    B-side length (Lb)
    26"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  37. 41-038

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    4 leaves
    A-side length (La)
    26-3/4"
    B-side length (Lb)
    28-3/4"
    Camber / free arch (C)
    7-3/8"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  38. 41-039

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    25-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    5-5/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  39. 41-040

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    4 leaves
    A-side length (La)
    26-3/4"
    B-side length (Lb)
    28"
    Camber / free arch (C)
    7-1/8"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  40. 41-041

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    12 leaves
    A-side length (La)
    25-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    4-1/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  41. 41-042

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    5 leaves
    A-side length (La)
    26-3/4"
    B-side length (Lb)
    28"
    Camber / free arch (C)
    6-5/8"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  42. 41-043

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    9 leaves
    A-side length (La)
    25-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    4-3/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  43. 41-044

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    26-1/8"
    B-side length (Lb)
    28-7/16"
    Camber / free arch (C)
    6-3/4"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  44. 41-045

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    3 leaves
    A-side length (La)
    17-1/8"
    B-side length (Lb)
    19-5/8"
    Camber / free arch (C)
    2-15/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  45. 41-046

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    26-1/8"
    B-side length (Lb)
    28-7/16"
    Camber / free arch (C)
    6-5/16"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  46. 41-047

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    11 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  47. 41-048

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    26-1/8"
    B-side length (Lb)
    28-7/16"
    Camber / free arch (C)
    6-1/16"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  48. 41-049

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    12 leaves
    A-side length (La)
    26"
    B-side length (Lb)
    26"
    Camber / free arch (C)
    3-5/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  49. 41-050

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    26-1/8"
    B-side length (Lb)
    28-7/16"
    Camber / free arch (C)
    6-1/8"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  50. 41-051

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    12 leaves
    A-side length (La)
    27-1/2"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    3-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  51. 41-052

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    26-1/8"
    B-side length (Lb)
    28-7/16"
    Camber / free arch (C)
    5-15/16"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  52. 41-053

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    15-7/8"
    B-side length (Lb)
    15-7/8"
    Camber / free arch (C)
    3-1/16"
    Width / thickness (W)
    2-1/2 width
    Part detailsOpen part page

  53. 41-054

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    11 leaves
    A-side length (La)
    26-1/2"
    B-side length (Lb)
    26-1/2"
    Camber / free arch (C)
    5-5/8"
    Width / thickness (W)
    3-1/2 width
    Part detailsOpen part page

  54. 41-055

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    12 leaves
    A-side length (La)
    30-1/4"
    B-side length (Lb)
    30-1/4"
    Camber / free arch (C)
    6-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  55. 41-056

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    26-1/8"
    B-side length (Lb)
    28-7/16"
    Camber / free arch (C)
    5-1/8"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  56. 41-057

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    14 leaves
    A-side length (La)
    30-1/4"
    B-side length (Lb)
    30-1/4"
    Camber / free arch (C)
    6-3/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  57. 41-058

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    26-1/8"
    B-side length (Lb)
    28-7/16"
    Camber / free arch (C)
    4-13/16"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  58. 41-059

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    12 leaves
    A-side length (La)
    27-1/2"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    3-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  59. 41-060

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    26-1/8"
    B-side length (Lb)
    28-7/16"
    Camber / free arch (C)
    5-3/4"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  60. 41-061

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    12 leaves
    A-side length (La)
    27-1/2"
    B-side length (Lb)
    29-1/2"
    Camber / free arch (C)
    3-3/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  61. 41-062

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    8 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    3-3/4"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  62. 41-063

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    13 leaves
    A-side length (La)
    27-1/2"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    3-1/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  63. 41-064

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    7 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    4-1/4"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  64. 41-065

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    12 leaves
    A-side length (La)
    27-1/2"
    B-side length (Lb)
    29-1/2"
    Camber / free arch (C)
    3-3/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  65. 41-066

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    3-1/8"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  66. 41-067

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    13 leaves
    A-side length (La)
    27-1/2"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    3-1/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  67. 41-068

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    3-3/4"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  68. 41-069

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    13 leaves
    A-side length (La)
    27-1/2"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    3-1/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  69. 41-070

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    3-3/4"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  70. 41-071

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    13 leaves
    A-side length (La)
    27-1/8"
    B-side length (Lb)
    28-5/8"
    Camber / free arch (C)
    3-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  71. 41-072

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    3-3/4"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  72. 41-074

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    8 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    4-7/16"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  73. 41-076

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    11 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    4-5/16"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  74. 41-078

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    26-1/8"
    B-side length (Lb)
    28-7/16"
    Camber / free arch (C)
    4-1/8"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  75. 41-080

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    29-1/8"
    B-side length (Lb)
    28-7/16"
    Camber / free arch (C)
    4-9/16"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  76. 41-082

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    5-9/16"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  77. 41-084

    Under development

    Pierce

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    26-1/8"
    B-side length (Lb)
    28-7/16"
    Camber / free arch (C)
    5-7/8"
    Width / thickness (W)
    4 width
    Part detailsOpen part page
