Reyco parts

01 / Search
Start with the part number, OEM reference, or application text you already have.
02 / Narrow
Use the filters to keep the closest matches in front of you.
03 / Check
Open the part page for measurements, references, and the right way to contact APM USA.

Matching parts

Reyco part pages in catalog

Split into 6 browse sections. Open the part page when the fit looks close.

156 shown part numbers are reference listings, not current catalog parts.

Part groups6
Part pages177
Reference156

Browse section

Rear · Multi-leaf

Use the part pages below. There is no separate family page for this group.

1 part page

This section only

  1. TRA2256

    Active catalog

    Reyco T3086

    1 OEM reference

    Position
    Rear
    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    7 leaves
    A-side length (La)
    21-7/8"
    B-side length (Lb)
    21-7/8"
    Camber / free arch (C)
    3-3/16"
    Width / thickness (W)
    Width 3" · Thickness 1/2"
    Part detailsOpen part page

Browse section

Air suspension · Air suspension

Use the part pages below. There is no separate family page for this group.

1 part page

This section only

  1. 83-167

    Active catalog

    Reyco 15676-01

    1 OEM reference

    Position
    Air suspension
    Spring group
    Air suspension
    Spring stage
    Single stage
    Air suspension style
    Hook type
    Leaf count
    1 leaves
    Eye-to-mount length (La)
    23-7/16"
    Mount-to-end length (Lb)
    18-3/4"
    Vertical rise (C)
    6-1/4"
    Width / thickness (W)
    Width 3" · Thickness 1-3/4"
    Part detailsOpen part page

Browse section

Multi-leaf

Use the part pages below. There is no separate family page for this group.

156 part pages

This section only

  1. 83-107

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    14 leaves
    A-side length (La)
    22-3/4"
    B-side length (Lb)
    23-3/4"
    Camber / free arch (C)
    4-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  2. 83-111

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    16 leaves
    A-side length (La)
    21-11/16"
    B-side length (Lb)
    22-1/8"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  3. 83-113

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    15 leaves
    A-side length (La)
    22-3/4"
    B-side length (Lb)
    23-3/4"
    Camber / free arch (C)
    3-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  4. 83-117

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    13 leaves
    A-side length (La)
    21-7/8"
    B-side length (Lb)
    21-7/8"
    Camber / free arch (C)
    4-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  5. 83-121

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    11 leaves
    A-side length (La)
    22-1/8"
    B-side length (Lb)
    22-1/8"
    Camber / free arch (C)
    3-7/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  6. 83-123

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    4 leaves
    A-side length (La)
    19"
    B-side length (Lb)
    24-1/8"
    Camber / free arch (C)
    4-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  7. 83-129

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    7 leaves
    A-side length (La)
    19"
    B-side length (Lb)
    24-7/16"
    Camber / free arch (C)
    2-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  8. 83-131

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    23-1/8"
    B-side length (Lb)
    23-1/8"
    Camber / free arch (C)
    4-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  9. 83-135

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    11 leaves
    A-side length (La)
    23-1/4"
    B-side length (Lb)
    23-1/4"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  10. 83-137

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    12 leaves
    A-side length (La)
    22-7/8"
    B-side length (Lb)
    22-7/8"
    Camber / free arch (C)
    3-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  11. 83-139

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    11 leaves
    A-side length (La)
    23-1/8"
    B-side length (Lb)
    23-1/8"
    Camber / free arch (C)
    4-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  12. 83-141

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    7 leaves
    A-side length (La)
    19"
    B-side length (Lb)
    24-1/16"
    Camber / free arch (C)
    2-3/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  13. 83-143

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    13 leaves
    A-side length (La)
    21-7/8"
    B-side length (Lb)
    21-7/8"
    Camber / free arch (C)
    4-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  14. 83-145

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    11 leaves
    A-side length (La)
    22-1/8"
    B-side length (Lb)
    22-1/8"
    Camber / free arch (C)
    3-7/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  15. 83-147

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    12 leaves
    A-side length (La)
    22-7/8"
    B-side length (Lb)
    22-7/8"
    Camber / free arch (C)
    4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  16. 83-149

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    14 leaves
    A-side length (La)
    21-1/16"
    B-side length (Lb)
    22-1/8"
    Camber / free arch (C)
    3-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  17. 83-151

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    31-7/8"
    B-side length (Lb)
    31-7/8"
    Camber / free arch (C)
    5-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  18. 83-153

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    31-7/8"
    B-side length (Lb)
    31-7/8"
    Camber / free arch (C)
    4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  19. 83-155

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    11 leaves
    A-side length (La)
    23-1/8"
    B-side length (Lb)
    23-1/8"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  20. 83-157

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    11 leaves
    A-side length (La)
    23-1/8"
    B-side length (Lb)
    23-1/8"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  21. 83-159

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    9 leaves
    A-side length (La)
    17-1/4"
    B-side length (Lb)
    21-1/2"
    Camber / free arch (C)
    2"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  22. 83-161

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    17-1/4"
    B-side length (Lb)
    21-1/2"
    Camber / free arch (C)
    2"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  23. 83-163

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    6 leaves
    A-side length (La)
    21-1/16"
    B-side length (Lb)
    22-1/8"
    Camber / free arch (C)
    3-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  24. 83-165

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    17 leaves
    A-side length (La)
    22-3/4"
    B-side length (Lb)
    23-5/8"
    Camber / free arch (C)
    4-3/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  25. 83-169

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    13 leaves
    A-side length (La)
    29-3/16"
    B-side length (Lb)
    29-3/16"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  26. 83-171

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    13 leaves
    A-side length (La)
    22-1/8"
    B-side length (Lb)
    22-1/8"
    Camber / free arch (C)
    4-3/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  27. 83-175

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    16 leaves
    A-side length (La)
    29-3/8"
    B-side length (Lb)
    29-3/8"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  28. 83-177

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    10 leaves
    A-side length (La)
    23-1/8"
    B-side length (Lb)
    23-1/8"
    Camber / free arch (C)
    4-7/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  29. 83-179

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    8 leaves
    A-side length (La)
    29"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    3-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  30. 83-181

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    32-1/4"
    B-side length (Lb)
    32-1/4"
    Camber / free arch (C)
    6-3/8"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  31. 83-183

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    6 leaves
    A-side length (La)
    32-1/4"
    B-side length (Lb)
    32-1/4"
    Camber / free arch (C)
    6-3/8"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  32. 83-185

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    21-1/2"
    B-side length (Lb)
    21-1/2"
    Camber / free arch (C)
    3"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  33. 83-187

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    32-1/4"
    B-side length (Lb)
    32-1/4"
    Camber / free arch (C)
    6-3/8"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  34. 83-189

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    7 leaves
    A-side length (La)
    32-1/4"
    B-side length (Lb)
    32-1/4"
    Camber / free arch (C)
    6-3/8"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  35. 83-191

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    11 leaves
    A-side length (La)
    29-3/4"
    B-side length (Lb)
    29-3/4"
    Camber / free arch (C)
    5-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  36. 83-193

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    SS"
    B-side length (Lb)
    SS"
    Camber / free arch (C)
    SS"
    Width / thickness (W)
    2.94 width
    Part detailsOpen part page

  37. 83-195

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    32-1/16"
    B-side length (Lb)
    32-1/16"
    Camber / free arch (C)
    6-3/16"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  38. 83-197

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    7 leaves
    A-side length (La)
    32-1/16"
    B-side length (Lb)
    32-1/16"
    Camber / free arch (C)
    6-3/16"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  39. 83-199

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    21-3/8"
    B-side length (Lb)
    21-3/8"
    Camber / free arch (C)
    2-3/4"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  40. 83-201

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    14 leaves
    A-side length (La)
    29-1/2"
    B-side length (Lb)
    29-1/2"
    Camber / free arch (C)
    5"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  41. 83-205

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    9 leaves
    A-side length (La)
    21-1/2"
    B-side length (Lb)
    21-1/2"
    Camber / free arch (C)
    2-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  42. 83-207

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    11 leaves
    A-side length (La)
    23-1/8"
    B-side length (Lb)
    23-1/8"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  43. 83-209

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    12 leaves
    A-side length (La)
    22-7/8"
    B-side length (Lb)
    22-7/8"
    Camber / free arch (C)
    4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  44. 83-211

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    11 leaves
    A-side length (La)
    23-1/8"
    B-side length (Lb)
    23-1/8"
    Camber / free arch (C)
    4-7/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  45. 83-213

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    22-7/8"
    B-side length (Lb)
    22-7/8"
    Camber / free arch (C)
    4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  46. 83-215

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    9 leaves
    A-side length (La)
    17-1/4"
    B-side length (Lb)
    21-1/2"
    Camber / free arch (C)
    2"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  47. 83-223

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    4 leaves
    A-side length (La)
    28-7/8"
    B-side length (Lb)
    28-7/8"
    Camber / free arch (C)
    5-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  48. 83-225

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    23-11/16"
    B-side length (Lb)
    23-3/16"
    Camber / free arch (C)
    5-7/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  49. 83-227

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    13 leaves
    A-side length (La)
    29-9/32"
    B-side length (Lb)
    29-9/32"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  50. 83-229

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    SS"
    B-side length (Lb)
    SS"
    Camber / free arch (C)
    SS"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  51. 83-231

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    2 leaves
    A-side length (La)
    13-25/32"
    B-side length (Lb)
    27-31/32"
    Camber / free arch (C)
    1-7/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  52. 83-233

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    13-25/32"
    B-side length (Lb)
    27-31/32"
    Camber / free arch (C)
    1-7/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  53. 83-237

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    14-5/32"
    B-side length (Lb)
    27-27/32"
    Camber / free arch (C)
    5/32"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  54. 83-241

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    14-5/32"
    B-side length (Lb)
    27-27/32"
    Camber / free arch (C)
    '-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  55. 83-243

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    23-1/8"
    B-side length (Lb)
    23-3/8"
    Camber / free arch (C)
    5-13/32"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  56. 83-245

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    23-1/8"
    B-side length (Lb)
    23-3/8"
    Camber / free arch (C)
    5-7/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  57. 83-247

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    23-1/8"
    B-side length (Lb)
    23-3/8"
    Camber / free arch (C)
    5-7/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  58. 83-249

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    23-1/8"
    B-side length (Lb)
    23-3/8"
    Camber / free arch (C)
    5-7/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  59. 83-251

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    2 leaves
    A-side length (La)
    14-5/32"
    B-side length (Lb)
    27-27/32"
    Camber / free arch (C)
    '-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  60. 83-253

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    2 leaves
    A-side length (La)
    14-5/32"
    B-side length (Lb)
    27-27/32"
    Camber / free arch (C)
    5/32"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  61. 83-255

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    SS"
    B-side length (Lb)
    SS"
    Camber / free arch (C)
    SS"
    Width / thickness (W)
    2.94 width
    Part detailsOpen part page

  62. 83-257

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    4 leaves
    A-side length (La)
    28-7/8"
    B-side length (Lb)
    28-7/8"
    Camber / free arch (C)
    5-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  63. 83-259

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    8 leaves
    A-side length (La)
    29-3/4"
    B-side length (Lb)
    29-3/4"
    Camber / free arch (C)
    5-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  64. 83-263

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    10 leaves
    A-side length (La)
    29-3/4"
    B-side length (Lb)
    29-3/4"
    Camber / free arch (C)
    5-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  65. 83-265

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    10 leaves
    A-side length (La)
    29-3/4"
    B-side length (Lb)
    29-3/4"
    Camber / free arch (C)
    5-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  66. 83-267

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    9 leaves
    A-side length (La)
    29-3/4"
    B-side length (Lb)
    29-3/4"
    Camber / free arch (C)
    5-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  67. 83-269

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    8 leaves
    A-side length (La)
    29-1/2"
    B-side length (Lb)
    29-1/2"
    Camber / free arch (C)
    5-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  68. 83-271

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    7 leaves
    A-side length (La)
    23-1/4"
    B-side length (Lb)
    23-5/8"
    Camber / free arch (C)
    5"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  69. 83-277

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    28-7/8"
    B-side length (Lb)
    28-7/8"
    Camber / free arch (C)
    5-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  70. 83-279

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    SS"
    B-side length (Lb)
    SS"
    Camber / free arch (C)
    SS"
    Width / thickness (W)
    2.94 width
    Part detailsOpen part page

  71. 83-281

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    SS"
    B-side length (Lb)
    SS"
    Camber / free arch (C)
    SS"
    Width / thickness (W)
    2.94 width
    Part detailsOpen part page

  72. 83-283

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    10 leaves
    A-side length (La)
    23-1/8"
    B-side length (Lb)
    23-1/8"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  73. 83-285

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    14 leaves
    A-side length (La)
    29-5/16"
    B-side length (Lb)
    29-5/16"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  74. 83-287

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    16 leaves
    A-side length (La)
    29-3/8"
    B-side length (Lb)
    29-3/8"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  75. 83-289

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    11 leaves
    A-side length (La)
    22-1/8"
    B-side length (Lb)
    22-1/8"
    Camber / free arch (C)
    3-13/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  76. 83-291

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    23-3/4"
    B-side length (Lb)
    23-3/4"
    Camber / free arch (C)
    5-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  77. 83-293

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    SS"
    B-side length (Lb)
    SS"
    Camber / free arch (C)
    SS"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  78. 83-295

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    23-5/8"
    B-side length (Lb)
    18-3/8"
    Camber / free arch (C)
    4-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  79. 83-297

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    23-5/8"
    B-side length (Lb)
    18-3/8"
    Camber / free arch (C)
    4-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  80. 83-299

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    20-1/4"
    B-side length (Lb)
    20-1/4"
    Camber / free arch (C)
    2-9/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  81. 83-301

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    3 leaves
    A-side length (La)
    23-11/16"
    B-side length (Lb)
    23-3/16"
    Camber / free arch (C)
    5-3/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  82. 83-303

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    4 leaves
    A-side length (La)
    23-1/4"
    B-side length (Lb)
    23-5/8"
    Camber / free arch (C)
    5"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  83. 83-305

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    SS"
    B-side length (Lb)
    SS"
    Camber / free arch (C)
    SS"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  84. 83-307

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    11 leaves
    A-side length (La)
    23-1/8"
    B-side length (Lb)
    23-1/8"
    Camber / free arch (C)
    4-7/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  85. 83-309

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    4 leaves
    A-side length (La)
    23-1/4"
    B-side length (Lb)
    23-5/8"
    Camber / free arch (C)
    5-7/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  86. 83-311

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    4 leaves
    A-side length (La)
    23-1/4"
    B-side length (Lb)
    23-5/8"
    Camber / free arch (C)
    5-7/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  87. 83-313

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    8 leaves
    A-side length (La)
    23-1/8"
    B-side length (Lb)
    23-1/8"
    Camber / free arch (C)
    4-9/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  88. 83-315

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    3 leaves
    A-side length (La)
    28-3/4"
    B-side length (Lb)
    28-3/4"
    Camber / free arch (C)
    5-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  89. 83-317

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    6 leaves
    A-side length (La)
    29"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    4-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  90. 83-323

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    5 leaves
    A-side length (La)
    29"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    4-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  91. TRA032

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    21-1/4"
    B-side length (Lb)
    22-1/4"
    Camber / free arch (C)
    4-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  92. TRA033

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    22-3/8"
    B-side length (Lb)
    22-3/8"
    Camber / free arch (C)
    6-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  93. TRA034

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    25-1/2"
    B-side length (Lb)
    25-1/2"
    Camber / free arch (C)
    6-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  94. TRA036

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    25-1/2"
    B-side length (Lb)
    26-11/16"
    Camber / free arch (C)
    7"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  95. TRA071

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    19-7/8"
    B-side length (Lb)
    19-7/8"
    Camber / free arch (C)
    4-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  96. TRA077

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    22-7/8"
    B-side length (Lb)
    22-7/8"
    Camber / free arch (C)
    6-11/16"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  97. TRA3302

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    11 leaves
    A-side length (La)
    23-1/8"
    B-side length (Lb)
    23-1/8"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  98. TRA3306

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    11 leaves
    A-side length (La)
    22-1/8"
    B-side length (Lb)
    22-1/8"
    Camber / free arch (C)
    3-7/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  99. TRA3308

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    3 leaves
    A-side length (La)
    22-1/2"
    B-side length (Lb)
    22-1/2"
    Camber / free arch (C)
    5"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  100. TRA3313

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    5 leaves
    A-side length (La)
    29-1/2"
    B-side length (Lb)
    29-1/2"
    Camber / free arch (C)
    3-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  101. TRA3314

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    6 leaves
    A-side length (La)
    29-1/2"
    B-side length (Lb)
    29-1/2"
    Camber / free arch (C)
    3-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  102. TRA3315

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    8 leaves
    A-side length (La)
    29-1/2"
    B-side length (Lb)
    29-1/2"
    Camber / free arch (C)
    3-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  103. TRA3316

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    9 leaves
    A-side length (La)
    32-1/4"
    B-side length (Lb)
    32-1/4"
    Camber / free arch (C)
    3-5/8"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  104. TRA3317

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    7 leaves
    A-side length (La)
    21-7/8"
    B-side length (Lb)
    21-7/8"
    Camber / free arch (C)
    4-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  105. TRA3318

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    7 leaves
    A-side length (La)
    29-1/2"
    B-side length (Lb)
    29-1/2"
    Camber / free arch (C)
    3-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  106. TRA3320

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    3 leaves
    A-side length (La)
    24-3/4"
    B-side length (Lb)
    24-3/4"
    Camber / free arch (C)
    6"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  107. TRA3321

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    8 leaves
    A-side length (La)
    29-1/16"
    B-side length (Lb)
    29-1/16"
    Camber / free arch (C)
    7-1/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  108. TRA3323

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    29-1/2"
    B-side length (Lb)
    29-1/2"
    Camber / free arch (C)
    3-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  109. TRA3324

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    4 leaves
    A-side length (La)
    25-5/16"
    B-side length (Lb)
    26"
    Camber / free arch (C)
    5-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  110. TRA3325

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    4 leaves
    A-side length (La)
    24-7/8"
    B-side length (Lb)
    24-7/8"
    Camber / free arch (C)
    4-7/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  111. TRA3326

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    3 leaves
    A-side length (La)
    24-15/16"
    B-side length (Lb)
    24-15/16"
    Camber / free arch (C)
    5-3/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  112. TRA3327

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    8 leaves
    A-side length (La)
    21-11/16"
    B-side length (Lb)
    21-11/16"
    Camber / free arch (C)
    3-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  113. TRA3333

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    8 leaves
    A-side length (La)
    24-1/8"
    B-side length (Lb)
    24-3/4"
    Camber / free arch (C)
    4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  114. TRA3337

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 2 OEM references

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    8 leaves
    A-side length (La)
    24-1/2"
    B-side length (Lb)
    25"
    Camber / free arch (C)
    4-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  115. TRA3342

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    7 leaves
    A-side length (La)
    23-1/2"
    B-side length (Lb)
    23-1/2"
    Camber / free arch (C)
    3-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  116. TRA3343

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    22-1/4"
    B-side length (Lb)
    22-1/4"
    Camber / free arch (C)
    2-5/8"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  117. TRA3353

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    14-5/8"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  118. TRA3354

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    14/58"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  119. TRA3355

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    14-5/8"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  120. TRA3356

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    15-7/8"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  121. TRA3357

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    15-7/8"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  122. TRA3358

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    15/7/8"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  123. TRA3359

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    15-7/8"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  124. TRA3360

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    15-7/8"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  125. TRA3361

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    25"
    B-side length (Lb)
    15-7/8"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  126. TRA3363

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    8 leaves
    A-side length (La)
    29"
    B-side length (Lb)
    29"
    Camber / free arch (C)
    3-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  127. TRA3364

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    11 leaves
    A-side length (La)
    28-3/8"
    B-side length (Lb)
    28-3/8"
    Camber / free arch (C)
    5-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  128. TRA3365

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    9 leaves
    A-side length (La)
    21-1/8"
    B-side length (Lb)
    21-1/8"
    Camber / free arch (C)
    2-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  129. TRA3366

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    6 leaves
    A-side length (La)
    29-1/2"
    B-side length (Lb)
    29-1/2"
    Camber / free arch (C)
    3-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  130. TRA3367

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    8 leaves
    A-side length (La)
    29-1/2"
    B-side length (Lb)
    29-1/2"
    Camber / free arch (C)
    3-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  131. TRA3368

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    12 leaves
    A-side length (La)
    31-7/8"
    B-side length (Lb)
    31-7/8"
    Camber / free arch (C)
    3-3/4"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  132. TRA3369

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    4 leaves
    A-side length (La)
    29-1/2"
    B-side length (Lb)
    29-1/2"
    Camber / free arch (C)
    3-5/8"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  133. TRA3370

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    5 leaves
    A-side length (La)
    29-1/2"
    B-side length (Lb)
    29-1/2"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  134. TRA3371

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    6 leaves
    A-side length (La)
    29-1/2"
    B-side length (Lb)
    29-1/2"
    Camber / free arch (C)
    3-1/2"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  135. TRA3372

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    9 leaves
    A-side length (La)
    31-3/4"
    B-side length (Lb)
    31-3/4"
    Camber / free arch (C)
    3-7/8"
    Width / thickness (W)
    5 width
    Part detailsOpen part page

  136. TRA3374

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    2 leaves
    A-side length (La)
    21-1/4"
    B-side length (Lb)
    23-7/16"
    Camber / free arch (C)
    4-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  137. TRA3375

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    2 leaves
    A-side length (La)
    21-1/2"
    B-side length (Lb)
    3-1/2"
    Camber / free arch (C)
    3-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  138. TRA3376

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    2 leaves
    A-side length (La)
    21-1/2"
    B-side length (Lb)
    3-1/2"
    Camber / free arch (C)
    3-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  139. TRA3378

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    9 leaves
    A-side length (La)
    28-3/8"
    B-side length (Lb)
    28-3/8"
    Camber / free arch (C)
    5-1/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  140. TRA3379

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    10 leaves
    A-side length (La)
    28-3/8"
    B-side length (Lb)
    28-3/8"
    Camber / free arch (C)
    5-3/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  141. TRA3380

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    21-1/2"
    B-side length (Lb)
    21-1/2"
    Camber / free arch (C)
    2-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  142. TRA3381

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Progressive
    Leaf count
    11 leaves
    A-side length (La)
    28-3/8"
    B-side length (Lb)
    28-3/8"
    Camber / free arch (C)
    5-1/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  143. TRA3382

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    2 leaves
    A-side length (La)
    22-3/16"
    B-side length (Lb)
    4"
    Camber / free arch (C)
    2-3/4"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  144. TRA3383

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    2 leaves
    A-side length (La)
    22-3/16"
    B-side length (Lb)
    4"
    Camber / free arch (C)
    2-3/4"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

  145. TRA3384

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    3 leaves
    A-side length (La)
    21-3/4"
    B-side length (Lb)
    22"
    Camber / free arch (C)
    3-3/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  146. TRA3386

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    2 leaves
    A-side length (La)
    21-7/8"
    B-side length (Lb)
    24-1/4"
    Camber / free arch (C)
    6-3/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  147. TRA3387

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    2 leaves
    A-side length (La)
    20-13/16"
    B-side length (Lb)
    4-3/16"
    Camber / free arch (C)
    3-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  148. TRA3388

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    2 leaves
    A-side length (La)
    20-13/16"
    B-side length (Lb)
    4-3/16"
    Camber / free arch (C)
    3-5/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  149. TRA3389

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    2 leaves
    A-side length (La)
    21-1/4"
    B-side length (Lb)
    21-1/4"
    Camber / free arch (C)
    5"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  150. TRA3390

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    15 leaves
    A-side length (La)
    28-3/8"
    B-side length (Lb)
    28-3/8"
    Camber / free arch (C)
    5-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  151. TRA3391

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    28-3/8"
    B-side length (Lb)
    28-3/8"
    Camber / free arch (C)
    5-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  152. TRA3392

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    11 leaves
    A-side length (La)
    28-3/8"
    B-side length (Lb)
    28-3/8"
    Camber / free arch (C)
    5-1/4"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  153. TRA3393

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    7 leaves
    A-side length (La)
    39-1/4"
    B-side length (Lb)
    39-1/4"
    Camber / free arch (C)
    2-1/2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  154. TRA3394

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    18-1/2"
    B-side length (Lb)
    18-7/16"
    Camber / free arch (C)
    2-7/8"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  155. TRA3395

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    8 leaves
    A-side length (La)
    19-1/2"
    B-side length (Lb)
    19-1/2"
    Camber / free arch (C)
    2"
    Width / thickness (W)
    3 width
    Part detailsOpen part page

  156. TRA3396

    Under development

    Reyco

    APM USA has this part number on file. It is not marked as a current catalog part. · 1 OEM reference

    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    22-1/4"
    B-side length (Lb)
    22-1/4"
    Camber / free arch (C)
    2-9/16"
    Width / thickness (W)
    4 width
    Part detailsOpen part page

Browse section

TR · Multi-leaf

Use the part pages below. There is no separate family page for this group.

11 part pages

This section only

  1. 83-115

    Active catalog

    Reyco TRAILER

    1 OEM reference

    Position
    TR
    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    11 leaves
    A-side length (La)
    23-1/8"
    B-side length (Lb)
    23-1/8"
    Camber / free arch (C)
    2-7/8"
    Width / thickness (W)
    Width 3" · Thickness 3/8"
    Part detailsOpen part page

  2. 83-127

    Active catalog

    Reyco NA

    1 OEM reference

    Position
    TR
    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    12 leaves
    A-side length (La)
    22-7/8"
    B-side length (Lb)
    22-7/8"
    Camber / free arch (C)
    3-1/4"
    Width / thickness (W)
    Width 3" · Thickness 3/8"
    Part detailsOpen part page

  3. 83-173

    Active catalog

    Reyco 102CC

    1 OEM reference

    Position
    TR
    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    14 leaves
    A-side length (La)
    29-3/8"
    B-side length (Lb)
    29-3/8"
    Camber / free arch (C)
    4-1/16"
    Width / thickness (W)
    Width 3" · Thickness 1/2"
    Part detailsOpen part page

  4. 83-217

    Active catalog

    Reyco

    1 OEM reference

    Position
    TR
    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    16 leaves
    A-side length (La)
    29-3/4"
    B-side length (Lb)
    29-3/4"
    Camber / free arch (C)
    3-1/2"
    Width / thickness (W)
    Width 3" · Thickness 1/2"
    Part detailsOpen part page

  5. 83-221

    Active catalog

    Reyco 79KB SUSP

    1 OEM reference

    Position
    TR
    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    11 leaves
    A-side length (La)
    29-11/16"
    B-side length (Lb)
    29-11/16"
    Camber / free arch (C)
    4-1/2"
    Width / thickness (W)
    Width 3" · Thickness 1/2"
    Part detailsOpen part page

  6. TRA2270

    Active catalog

    Reyco TRAILER

    1 OEM reference

    Position
    TR
    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    8 leaves
    A-side length (La)
    21-11/16"
    B-side length (Lb)
    21-11/16"
    Camber / free arch (C)
    2-13/16"
    Width / thickness (W)
    Width 3" · Thickness 1/2"
    Load capacity
    11000 lbs
    Part detailsOpen part page

  7. TRA2291

    Active catalog

    Reyco 08376-01

    1 OEM reference

    Position
    TR
    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    3 leaves
    A-side length (La)
    21-7/8"
    B-side length (Lb)
    22-3/8"
    Camber / free arch (C)
    2-15/16"
    Width / thickness (W)
    Width 3" · Thickness 13/16"
    Part detailsOpen part page

  8. TRA2297

    Active catalog

    Reyco TRAILER

    1 OEM reference

    Position
    TR
    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    9 leaves
    A-side length (La)
    21-3/8"
    B-side length (Lb)
    21-3/8"
    Camber / free arch (C)
    1-7/8"
    Width / thickness (W)
    Width 3" · Thickness 1/2"
    Part detailsOpen part page

  9. TRA2297 HD

    Active catalog

    Reyco

    TR leaf spring catalog record for Reyco.

    Position
    TR
    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    10 leaves
    A-side length (La)
    21-3/8"
    B-side length (Lb)
    21-3/8"
    Camber / free arch (C)
    1-7/8"
    Width / thickness (W)
    Width 3" · Thickness 1/2"
    Part detailsOpen part page

  10. TRA3309

    Active catalog

    Reyco 0178-01

    1 OEM reference

    Position
    TR
    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    8 leaves
    A-side length (La)
    21-1/2"
    B-side length (Lb)
    22-7/8"
    Camber / free arch (C)
    3-1/4"
    Width / thickness (W)
    Width 3" · Thickness 1/2"
    Part detailsOpen part page

  11. TRA3340 HD

    Active catalog

    Reyco

    TR leaf spring catalog record for Reyco.

    Position
    TR
    Spring group
    Multi-leaf
    Spring stage
    Single stage
    Leaf count
    4 leaves
    A-side length (La)
    21-3/16"
    B-side length (Lb)
    24-1/4"
    Camber / free arch (C)
    3-5/16"
    Width / thickness (W)
    Width 3" · Thickness 13/16"
    Part detailsOpen part page

Browse section

L · Parabolic

Use the part pages below. There is no separate family page for this group.

1 part page

This section only

  1. 83-261

    Active catalog

    Reyco 16286-01

    3 OEM references

    Position
    L
    Spring group
    Parabolic
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    20-1/4"
    B-side length (Lb)
    20-1/4"
    Camber / free arch (C)
    2-5/8"
    Eye Diameter (Ø Eye)
    0"
    Part detailsOpen part page

Browse section

TR · Parabolic

Use the part pages below. There is no separate family page for this group.

7 part pages

This section only

  1. 83-133

    Active catalog

    Reyco 12858-01

    1 OEM reference

    Position
    TR
    Spring group
    Parabolic
    Spring stage
    Single stage
    Leaf count
    3 leaves
    A-side length (La)
    22-1/8"
    B-side length (Lb)
    22-5/16"
    Camber / free arch (C)
    3-1/4"
    Width / thickness (W)
    Width 3" · Thickness 13/16"
    Part detailsOpen part page

  2. 83-273

    Active catalog

    Reyco HP48210-1500A

    1 OEM reference

    Position
    TR
    Spring group
    Parabolic
    Spring stage
    Single stage
    Leaf count
    4 leaves
    A-side length (La)
    28-5/8"
    B-side length (Lb)
    28-5/8"
    Camber / free arch (C)
    4-5/8"
    Width / thickness (W)
    Width 3" · Thickness 15/16"
    Part detailsOpen part page

  3. 83-275

    Active catalog

    Reyco 16227-06

    1 OEM reference

    Position
    TR
    Spring group
    Parabolic
    Spring stage
    Single stage
    Leaf count
    3 leaves
    A-side length (La)
    23-11/16"
    B-side length (Lb)
    23-3/16"
    Camber / free arch (C)
    5-3/8"
    Width / thickness (W)
    Width 3" · Thickness 13/16"
    Part detailsOpen part page

  4. TRA031

    Active catalog

    Reyco TRAILER

    1 OEM reference

    Position
    TR
    Spring group
    Parabolic
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    21-15/16"
    B-side length (Lb)
    21-3/4"
    Camber / free arch (C)
    2-15/16"
    Width / thickness (W)
    Width 3" · Thickness 1-3/8"
    Part detailsOpen part page

  5. TRA035

    Active catalog

    Reyco TRAILER

    1 OEM reference

    Position
    TR
    Spring group
    Parabolic
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    18-1/2"
    B-side length (Lb)
    18-1/2"
    Camber / free arch (C)
    2-11/16"
    Width / thickness (W)
    Width 3" · Thickness 1-3/8"
    Load capacity
    11000 lbs
    Part detailsOpen part page

  6. TRA037

    Active catalog

    Reyco NA

    1 OEM reference

    Position
    TR
    Spring group
    Parabolic
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    22-13/16"
    B-side length (Lb)
    21-1/2"
    Camber / free arch (C)
    6-1/8"
    Width / thickness (W)
    Width 3" · Thickness 1-1/2"
    Part detailsOpen part page

  7. TRA038

    Active catalog

    Reyco TRAILER

    2 OEM references

    Position
    TR
    Spring group
    Parabolic
    Spring stage
    Single stage
    Leaf count
    1 leaves
    A-side length (La)
    21-5/8"
    B-side length (Lb)
    22-5/16"
    Camber / free arch (C)
    4-3/16"
    Width / thickness (W)
    Width 3" · Thickness 1-5/8"
    Part detailsOpen part page
